CPM-100G5
4 inch Wide Sign and Label Printing & Cutting Machine
MAX CPM-100G5 4 inch wide sign and label printing and cutting machine. The CPM-100G5 combines thermal print and vinyl-cutting technology, together with our tried and tested software, to produce multiple spot-color outputs.
Applications
- ANSI and OSHA Agency Required Signage
- Health & Safety Signs
- Product & Asset Labelling
- Visual Management Signs
- Pipe Marking / GHS Labels
- 5S / Kaizen / Kanban Labels
- Custom Labels
Features
- You can create your own signs and labels wherever and whenever you want them with MAX CPM system
- Print custom labels and signs in-house with the MAX CPM system. You can save money by eliminating waste and decreasing purchasing costs.
- Variable information from your database saved in CSV format, can be linked directly to your label designs
- Cuts any shapes and size freely to suit your signs and labeling needs
- Prints UPC, QR codes and much more
- MAX Bepop PC-EX software has over 1,400 symbols and templates
Specifications
|
DIMENSIONS
|
320mm(H) x 330mm(W) x 320mm(L) |
|---|---|
|
WEIGHT
|
9 kg |
PRINT TECHNOLOGY | Thermal Transfer |
COLOR PRINTING CAPABILITY | Multi-Color |
PRINT RESOLUTION | 203 dpi |
PRINTING SPEED | 25 mm/sec. |
CUTTING SPEED | 120 mm/sec. |
CUTTING FUNCTION | Free-cut (Shapes, Letters, Bordering, etc.) |
MAXIMUM OUTPUT RANGE | 100 mm x 2000 mm |
MAXIMUM PRINT WIDTH | 25 mm |
CONNECTIVITY | USB2.0 Full Speed |
OPERATING TEMPERATURE | 10-35℃ |
OPERATING HUMIDITY | 35-80%, non-condensing |
POWER SUPPLY VOLTAGE | AC 100-240V |
Consumables
| Description | Label / Ribbon size | Color | Material | Package | |
|---|---|---|---|---|---|
| PREMIUM TAPE ROLL | SL-S111GN BLACK PREMIUM TAPE ROLL | 4 in W x 49 ft L | BLACK | GLOSSY PVC | 1roll/box |
| PREMIUM TAPE ROLL | SL-S112GN WHITE PREMIUM TAPE ROLL | 4 in W x 49 ft L | WHITE | GLOSSY PVC | 1roll/box |
| PREMIUM TAPE ROLL | SL-S113GN RED PREMIUM TAPE ROLL | 4 in W x 49 ft L | RED | GLOSSY PVC | 1roll/box |
| PREMIUM TAPE ROLL | SL-S114GN BLUE PREMIUM TAPE ROLL | 4 in W x 49 ft L | BLUE | GLOSSY PVC | 1roll/box |
| PREMIUM TAPE ROLL | SL-S115GN YELLOW PREMIUM TAPE ROLL | 4 in W x 49 ft L | YELLOW | GLOSSY PVC | 1roll/box |
| PREMIUM TAPE ROLL | SL-S116GN GREEN PREMIUM TAPE ROLL | 4 in W x 49 ft L | GREEN | GLOSSY PVC | 1roll/box |
| PREMIUM TAPE ROLL | SL-S118GN ORANGE PREMIUM TAPE ROLL | 4 in W x 49 ft L | ORANGE | GLOSSY PVC | 1roll/box |
| PREMIUM TAPE ROLL | SL-S110GN CLEAR PREMIUM TAPE ROLL | 4 in W x 49 ft L | CLEAR | GLOSSY PVC | 1roll/box |
| PREMIUM TAPE ROLL | SL-S126GN BROWN PREMIUM TAPE ROLL | 4 in W x 49 ft L | BROWN | GLOSSY PVC | 1roll/box |
| PREMIUM TAPE ROLL | SL-S108GN SILVER PREMIUM TAPE ROLL | 4 in W x 49 ft L | SILVER | GLOSSY PVC | 1roll/box |
| PREMIUM TAPE ROLL | SL-S109GN GOLD PREMIUM TAPE ROLL | 4 in W x 49 ft L | GOLD | GLOSSY PVC | 1roll/box |
| SPECIAL TAPE ROLL | SL-S163N PET HL SILVER TAPE ROLL | 4 in W x 49 ft L | HAIR-LINED SILVER | POLYESTER | 1roll/box |
| SPECIAL TAPE ROLL | SL-S164N PET HL GOLD TAPE ROLL | 4 in W x 49 ft L | HAIR-LINED GOLD | POLYESTER | 1roll/box |
| SPECIAL TAPE ROLL | SL-S153N PET WHITE TAPE ROLL | 4 in W x 33 ft L | WHITE | POLYESTER | 2rolls/box |
| SPECIAL TAPE ROLL | SL-S154N PET MAT SILVER TAPE ROLL | 4 in W x 33 ft L | MAT SILVER | POLYESTER | 2rolls/box |
| SPECIAL TAPE ROLL | SL-S141N REFLECTIVE WHITE TAPE ROLL | 4 in W x 33 ft L | WHITE | REFLECTIVE | 2rolls/box |
| SPECIAL TAPE ROLL | SL-S100AP APPLICATION SHEET | 4 in W x 65 ft L | 2rolls/box | ||
| SPECIAL TAPE ROLL | SL-L100 FLOOR LAMINATE (80 micron) | 4 in W x 98 ft L | 1roll/box | ||
| INK RIBBON | SL-R101T BLACK-C RIBBON | 4 in W x 180 ft L | BLACK | RESIN | 1pc |
| INK RIBBON | SL-R122TH SUPER WHITE RIBBON | 4 in W x 180 ft L | WHITE | RESIN | 1pc |
| INK RIBBON | SL-R103T RED-C RIBBON | 4 in W x 180 ft L | RED | RESIN | 1pc |
| INK RIBBON | SL-R104T BLUE-C RIBBON | 4 in W x 180 ft L | BLUE | RESIN | 1pc |
| INK RIBBON | SL-R105T DARK BLUE-C RIBBON | 4 in W x 180 ft L | DARK BLUE | RESIN | 1pc |
| INK RIBBON | SL-R106T DARK GREEN RIBBON | 4 in W x 180 ft L | DARK GREEN | RESIN | 1pc |
| INK RIBBON | SL-R107T GREEN-C RIBBON | 4 in W x 180 ft L | GREEN | RESIN | 1pc |
| INK RIBBON | SL-R108T YELLOW-C RIBBON | 4 in W x 180 ft L | YELLOW | RESIN | 1pc |
| INK RIBBON | SL-R112T ORANGE-C RIBBON | 4 in W x 180 ft L | ORANGE | RESIN | 1pc |
| ACCESSORIES | CM-B20E BLADE | 1pc |
Manuals/Videos
Owner's Manual
DownloadBasic use of Bepop PC-EX software
Watch VideoAuto copy, serial & barcode serial numbering
Watch VideoBasic use of CSV database connection
Watch VideoMore advanced CSV database connection
Watch VideoImporting image data as vector image
Watch VideoIntroduction of symbols and templates data
Watch VideoIntroduction of other various function
Watch Video
